D600 MM

The D600 CNC spinning machine is a universal double-wheel CNC spinning machine developed by our company. It can spin products with diameters below 500mm and has complete equipment and technology. The Siemens mid-to-high-end system 808d, with remote network diagnosis and maintenance functions, greatly facilitates the use of machine tools for foreign customers. It can be used with our SpinningCadV2.1 version spinning software.

$1.00$0.00

Have chosen: There are no options selected

Start To Order

Add To Cart Successfully!

D600 MM

D600 MM

The D600 CNC spinning machine is a universal double-wheel CNC spinning machine developed by our company. It can spin products with diameters below 500mm and has complete equipment and technology. The Siemens mid-to-high-end system 808d, with remote network diagnosis and maintenance functions, greatly facilitates the use of machine tools for foreign customers. It can be used with our SpinningCadV2.1 version spinning software.


  • Product Code:CNC METAL SPINNING MACHINE-D600MM
  • Size3100 x 2000 x 1800 m
    Weight:3700 kg

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Processing method: horizontal CNC spinning
Raw material diameter: maxФ600
Product length: 620mm
Material: Aluminum, copper, carbon steel, stainless steel and other materials
Thickness range: max 2.5mm (tensile strength is about 380MPa ordinary carbon steel)
max 4mm (The tensile strength is about 230Mpa aluminum)
Technical index
X axial displacement 250mm
Z axial displacement 900mm
X, Z moving speed max 5m/min
X, Z axis rated thrust 20KN
Axial positioning accuracy 0.02mm
Repeatability 0.02mm
Spindle speed: 0——800rpm
Processing method: horizontal CNC spinning
Raw material diameter: maxФ600
Product length: 620mm
Material: Aluminum, copper, carbon steel, stainless steel and other materials
Thickness range: max 2.5mm (tensile strength is about 380MPa ordinary carbon steel)
max 4mm (The tensile strength is about 230Mpa aluminum)
Technical index
X axial displacement 250mm
Z axial displacement 900mm
X, Z moving speed max 5m/min
X, Z axis rated thrust 20KN
Axial positioning accuracy 0.02mm
Repeatability 0.02mm
Spindle speed: 0——800rpm
