The maximum turning diameter of the middle pallet MM 550
Maximum blank diameter mm 800
Double center distance (distance from spindle center to tail top center) mm 1000
Main motor kW 22
X axis travel MM unilateral 400
Maximum thrust of X axis KN 60
Maximum moving speed of X axis mm/min 7500
Z axis travel MM 600
Maximum thrust of Z axis KN 60
Maximum moving speed of Z axis mm/min 6000
Spindle speed rpm 50-1500
Tail top force KN 20
Top stroke mm 700
Number of tools (rotating wheel) pieces 6+6
Processing aluminum thickness mm 0.5-6
Processing ordinary steel thickness mm 0.5-4
Processing stainless steel thickness mm 0.5-3
Machine size mm 4060*2000*1600
Spindle flange connection method GB A2-8
Machine weight KG 7000
